steellabWe supply Reducing Pipe/Head/Pipe Clip, select your favorite Marine Hardware/Tools/Bearing to send us an inquiry email or leave us a message, we will contact you within 24 hours, for your quotation.
| Characteristics | Polypropylene | Nylon |
| Density | 0.906g/cm2 | 1.12-1.15g/cm3 |
| Bending strength | 36N/mm2 | 130…200N/mm2 |
| Impact toughness | no bteak | no bteak |
| Compression strength | 90N/mm2 | 120N/mm2 |
| Elastic modulus | 1500N/mm2 | 3000N/mm2 |
| Tensile strength | 25-35N/mm2 | 80-90N/mm2 |
| Temperature resistant | -30… 90 ℃ | -40… 120 ℃ |
| Color | Green, Blue | Black |
Product and material composition: Bolts: Carbon steel (Level 4.8 or 8.8)/stainless steel (XUS304 or XUS316) cover: Carbon steel (galvanized or phosphating)/stainless steel (XUS304 or XUS316)Pipe clamping Body: PP/PA/AL/Q235/SS304/XS316 welded bottom Plate: carbon steel (galvanized or phosphating)/stainless steel (XUS304 or XUS316)
Rail nuts: Carbon steel (galvanized or phosphating)/stainless steel (XUS304 or XUS316)
Mounting rails: Carbon steel (galvanized or phosphating)/stainless steel (XUS304 or XUS316)
Operating temperature: plastic Pp-30℃to+90℃; nylon Pa-40℃to+120℃; aluminum alloy Al-80℃to+300℃; steel Q235a-80℃to+500℃; stainless steel Ss304/ss316-80℃to+500℃. Application areas: This product is suitable for metallurgy, petroleum, chemical industry, vehicles, ships, electricity and other mechanical hydraulic systems in the oil, water, gas as a medium fixed pipe.
Lightweight Series tube clamps are suitable for medium and low voltage (PN≤8Mpa) pipe fixing.
Lightweight Series Tube Clamp is suitable for 6 sizes of ordinary mechanical pressure pipe, pipe outer diameter 6-102mm. This type of pipe clamp fittings include rail nuts, tube clamps and inner hexagonal bolts, usually used in conjunction with light rails, for piping requiring displacement.
